Chint 6kA 3P 40A Breaker C-Curve

The CHINT 6kA 3P 40A Circuit Breaker C-Curve is a CHINT NXB-63 series miniature circuit breaker (MCB) that protects AC circuits against overload and short-circuit faults, and can also isolate a circuit for safe maintenance.

Built to IEC/EN 60898-1 with a 40A rated current, a 6kA breaking capacity and a three-pole design, it provides reliable thermal-magnetic protection. The C-curve trip characteristic suits general-purpose loads with moderate inrush such as socket circuits, lighting and small motors. It clips onto a standard 35 mm DIN rail for quick, tidy installation in your distribution board.

• 6kA breaking capacity
• 40A rated current
• Three-pole (3P)
• C-curve trip characteristic
• Compliant with IEC/EN 60898-1
• 35 mm DIN-rail mountable
• Genuine CHINT product

Sonop Solar supplies and delivers genuine products nationwide across South Africa, with priority support for customers in the Western Cape. We don’t install — but we can refer you to a trusted, accredited installer from our network.
